D4S D4R LED BULBS MAGALL HID-LED 12000lm 6500K 70W XENON REPLACEMENTS

⭐ 1:1 LED replacements for traditional xenon bulbs, Plug and Play system

⭐ Compatible with original sockets

⭐ Simple, quick installation with no complicated vehicle modifications – saves time and money.

⚙️Set of two ultra-bright LED bulbs

⚙️ System: 12V/24V

⚙️Voltage from the xenon ballast: 42V AC

⚙️Power: 70W (pair)

⚙️Luminous flux: 12000LM (pair)

⚙️Colour: 6500K cool white

⚙️Compatible with xenon sockets: D4S, D4R

⚙️ LED chip: 7741 CSP

⚙️2 LED chips with 30 light units per bulb

⚙️Quiet cooling fan with ball bearing

(12,000 rpm)

⚙️ CANBUS

⚙️Made of aluminium and copper

⚙️Operating temperature:  -40~80℃

Easy installation and use

✅Simple 1:1 installation: HID-LED bulbs are designed for simple installation without modifying the wiring. Just connect them like traditional xenon bulbs and enjoy modern lighting without unnecessary complications.

✅Powered directly from the ballast: the LED bulbs are powered directly from the high-voltage ballast that feeds standard xenon burners. There is no need to remove the ballast – just connect the LED burners to it using the standard plugs. This avoids modifying the electrical system and makes fitting and removal quick and easy.

✅Compatible with original ballasts: these LED bulbs are designed to work with original ballasts, ensuring smooth, trouble-free integration with your vehicle's existing lighting system.

 WATER RESISTANCE

☂️Full protection against moisture: with an IP65 rating, MAGALL HID-LED bulbs are fully resistant to rain, moisture and dust. Even in difficult weather such as downpours or mud, they work reliably and keep you safe on the road.

☂️Durability and longer life: the solid, sealed construction of MAGALL HID-LED bulbs effectively prevents corrosion and damage, extending their life. A durable solution for every situation.

☂️Safety in all conditions: by choosing MAGALL HID-LED bulbs with IP65 water resistance, you can be sure your lighting will work without failure whatever the weather. The ideal choice for drivers who value reliability and quality on every journey.

CANBUS

✅CANBUS system: A special CANBUS system eliminates the bulb failure problem in most cases, ensuring trouble-free operation.

✅Two LED chips per bulb: each bulb contains two LED chips with 15 light units each, providing bright, stable light. CSP (Chip Scale Package) means better efficiency and longer life. The LEDs use high-quality 6500K CSP chips, giving strong, clear white light.

Active cooling for stable operation

A quiet ball-bearing fan helps dissipate heat effectively and maintain a stable operating temperature.

✔️ efficient cooling

✔️ quiet operation

✔️ longer LED life

✔️ stable light output

⭐High build quality⭐

✅Premium materials: made of high-quality aluminium and copper, these bulbs dissipate heat excellently, giving a longer life and reliability. Copper in the design allows efficient heat conduction, significantly improving cooling and performance.

✅Quiet cooling fan: the bulbs have a quiet ball-bearing cooling fan running at 12,000 rpm. This provides efficient cooling with minimal noise, for a longer life and quiet operation of the lighting system.

⭐Unmatched brightness and efficiency⭐

✅Unmatched brightness: HID-LED bulbs offer an impressive 12,000 lumens per pair (6,000 lumens per bulb), providing excellent road illumination that increases safety and driving comfort.

✅Cool white light: a colour temperature of 6500K (cool white) delivers bright, clean light that is easy on the eyes and lights up every route effectively.

✅70W per set (35W per bulb): efficient and energy-saving, these LED bulbs deliver maximum performance with minimal energy consumption.

✅Important product information – benefits and safety rules

1. Operating temperature – modern and controlled Our LED bulbs reach a temperature of about 100°C during operation. This is a normal, fully controlled design feature that shows they are working correctly and efficiently.

2. Safety for your car – a key advantage over tradition Unlike our LEDs, traditional halogen car bulbs generate extreme heat. The temperature of their glass bulb reaches 200°C to as much as 250°C! Thanks to a much lower operating temperature, our LED bulbs are 100% safe for factory lamps and headlights. There is no risk of damage, clouding or melting, a common problem with overheating halogens.

3. Warning – your safety during installation Remember that even 100°C can cause burns. Always avoid touching the bulb while it is on and immediately after switching it off. Before fitting or removing it, wait a few moments to be sure it has cooled down completely.

⭐MAGALL LED Bulbs – Safety and Compliance with EU Standards⭐

MAGALL LED bulbs comply with the EMC Directive 2014/30/EU and have passed EN IEC 55015:2019+A11:2020 testing.

MAGALL bulbs are designed not to interfere with other electrical devices and are resistant to external electromagnetic interference. This means stable, trouble-free operation throughout their service life, adding to the convenience, safety and comfort of everyday use of MAGALL LED lighting.

MAGALL LED bulbs carry the CE mark and meet European Union requirements for safety, health and environmental protection. The CE mark shows that the products have been tested for safe use and meet the strict quality and technical standards required in the EU.

☝️Are LED bulbs type-approved (homologated)?

All LED light sources available on the market were designed for headlights that meet the standards for halogen or conventional bulbs. The European Union has not yet adopted the comprehensive regulations needed to legalise LED retrofit light sources. When some sellers present information in their listings suggesting that LED bulbs are type-approved, this is intended to mislead customers into buying. Some of them even put an E… mark on the product to reinforce this impression. We do not use such practices.

In the European Union, automotive products must have UNECE certification to be used on public roads. Existing ECE certificates cover only halogen and xenon bulbs and LED light sources fitted as original equipment in new vehicles. However, there are no specific type-approval requirements or restrictions on using LED light sources on private roads, race tracks, etc. That is why leading manufacturers of automotive LED lighting mark their products "off-road use only" or "not for use on public roads".

Although the law has not changed, we believe our customers now know enough about LED light sources to make an informed choice and a satisfying purchase.

All our products comply with the EMC Directive 2014/30/EU – CE

and are tested to EN IEC 55015:2019+A11:2020 and EN 61547:2009

CANBUS – how it works and why it matters for LED bulbs

CAN BUS (Controller Area Network Bus) is a car's internal communication network that lets electronic modules (e.g. the BCM – Body Control Module) exchange data without extra wiring.

The computer does not check whether the bulb actually lights up – it measures the current draw and the circuit resistance.

• Test when the ignition is switched on: the computer sends a short pulse and checks whether the resistance falls within the so-called acceptance window, i.e. the permitted range of values.
• Continuous measurement while driving: in more advanced cars the BCM constantly monitors the current. If the LED bulb has different characteristics from a halogen (e.g. lower current draw), the system may treat this as a fault and display a "bulb out" message.

In practice, different cars have different tolerance ranges and CANBUS standards – they differ in data transfer speed, how the circuit is tested, and resistance and power draw requirements.

So saying that an LED bulb "has CANBUS" or "doesn't have CANBUS" is a simplification. It all depends on the tolerance of the vehicle's diagnostic system and the parameters of the LED bulb itself.

An illustrative example of how it works:

an H7 halogen bulb has a resistance of 3,6Ω

1.

• an example H7 LED bulb has a resistance of 10 Ω
• car A (acceptable range) 2,5–7 Ω – warning
• car B (acceptable range) 2–12 Ω – no warning
• car C (acceptable range) 3–5 Ω – warning

2.

• an example H7 LED bulb has a resistance of 6 Ω
• car A (acceptable range) 2,5–7 Ω – no warning
• car B (acceptable range) 2–12 Ω – no warning
• car C (acceptable range) 3–5 Ω – warning

3.

• an example H7 LED bulb has a resistance of 2,5 Ω
• car A (acceptable range) 2,5–7 Ω – no warning
• car B (acceptable range) 2–12 Ω – no warning
• car C (acceptable range) 3–5 Ω – warning (short circuit)

Now you know why the same bulbs work without warnings for some users while for others the on-board computer reports a problem.

In our listings we state the technical parameters preciselyto make it easier to choose bulbs for a specific car model and avoid misunderstandings.
