W16W T15 LED Bulbs CANBUS White Bright MAGALL FAN-CAN 6500K 1000 lm 12V

Description

W16W T15 LED BULBS CANBUS WHITE BRIGHT MAGALL FAN-CAN 6500K 1000LM 12V

Looking for reliable, efficient LED bulbs for your vehicle? Choose MAGALL FAN-CAN W16W T15 LED bulbs, which combine modern technology, high brightness and durability.

MAGALL FAN-CAN LED bulbs are built from top-quality materials.

• Special aluminium alloy
• Passive heat sink
• Korean LED CHIPS covered with a silicone lens that protects them and acts as an optic, improving light output through proper refraction and diffusion.

All this makes them exceptional bulbs that are very durable and weather-resistant.

✅ Service life – 5 YEARS or 100,000 km!

⚙️TECHNICAL SPECIFICATIONS⚙️

• Fitting: W16W T15
• Base type: W2.1x9.5d
• Supply: 12V
• Power: 10W
• Current: 0.7 A
• Resistance: 20Ω
• Luminous flux: 1000 lm
• Light colour: 6500K – cool white
• LED type: 7035 CSP LED
• Length: 38 mm
• Width (heat sink): 15.5 mm
• Base diameter: 10 mm
• Material: copper PCB + 6063 aviation aluminium housing
• Operating temperature: -40°C to +80°C
• Water resistance: IP65

For comparison, the specifications of standard W16W bulbs

• Luminous flux: 310LM
• Power: 16 W
• Current: 1.2 A
• Resistance: 12Ω

✅ Efficient cooling = longer life and reliability

MAGALL FAN-CAN W16W T15 LED bulbs are designed for maximum efficiency and durability. Their design is based on two key elements:

• 6063 aviation aluminium housing: this aluminium alloy has high thermal conductivity, effectively removing the heat generated by the LEDs. The bulbs stay at their optimal operating temperature, giving a longer life and stable operation.
• Copper PCB: copper, an excellent heat conductor, spreads heat from the LEDs over the whole bulb. This minimises the risk of the electronic components overheating, keeping them reliable even in harsh conditions.

Thanks to this advanced design, MAGALL FAN-CAN W16W T15 LED bulbs offer:

• Stable, even light with no flickering,
• Longer life than standard LED bulbs,
• Resistance to temperature changes and humidity thanks to the IP65 rating.

All this makes them the ideal choice for drivers looking for reliable, durable lighting for their vehicle.

✅95% CANBUS system – no on-board computer errors

The built-in CANBUS system eliminates errors caused by switching to LED bulbs, for trouble-free use with no extra modifications.

✅High brightness and even light – excellent visibility and style

MAGALL FAN-CAN W16W T15 LED bulbs use modern OEM 7035 CSP LEDs that emit intense light of 1000 lumens at 6500K. This guarantees not only excellent visibility but also a modern look for your vehicle.

✅Benefits of OEM 7035 CSP LEDs:

• High luminous efficiency: these LEDs provide strong, focused light that illuminates the area around the vehicle excellently.
• Even light distribution: precise LED placement spreads the light evenly, eliminating dark zones and improving driving comfort.
• 6500K cool white: ideal for interior, boot and number plate lighting or as reverse lights, giving any car a modern character.

Thanks to these features, W16W T15 LED bulbs are an excellent choice for drivers looking for reliable, good-looking lighting.

✅Trouble-free installation – 1:1 Plug & Play replacement

MAGALL FAN-CAN W16W T15 LED bulbs are designed for maximum convenience. With the standard W16W T15 fitting and W2.1x9.5d base, installation is extremely simple and needs no modifications or tools.

Plug & Play installation features:

• 1:1 replacement: the new bulbs have exactly the same dimensions as traditional halogen bulbs (length: 38 mm, width: 15.5 mm, base diameter: 10 mm), allowing direct replacement without adapting the holder.

IP65 water resistance features:

☂️Dust-tight: complete protection against dust ingress, important in very dusty environments.

☂️Resistant to water jets: protects against jets of water, so the bulbs are safe when washing the vehicle or driving in rain.

Thanks to these properties, MAGALL FAN-CAN W16W T15 LED bulbs guarantee reliable operation and a long life whatever the weather.

✅Applications:

• Reverse lights: strong, bright light makes manoeuvring in the dark easier, increasing safety when reversing.
• Turn signals: fast response and clear light improve communication with other road users.
• Fog lights: increase visibility in difficult weather such as fog or heavy rain.
• Boot lighting: bright, even light makes it easy to use the boot, even in total darkness.

MAGALL is a brand focused on solid build quality and high luminous efficiency. Our W16W LED bulbs are a premium solution – energy-saving, durable and extremely efficient. Thanks to their design and high-quality materials, our bulbs are very durable, eliminating the short-life problems of typical LED bulbs.

✅Important product information – benefits and safety rules

1. Operating temperature – modern and controlled Our LED bulbs reach a temperature of about 100°C during operation. This is a normal, fully controlled design feature that shows they are working correctly and efficiently.

2. Safety for your car – a key advantage over tradition Unlike our LEDs, traditional halogen car bulbs generate extreme heat. The temperature of their glass bulb reaches 200°C to as much as 250°C! Thanks to a much lower operating temperature, our LED bulbs are 100% safe for factory lamps and headlights. There is no risk of damage, clouding or melting, a common problem with overheating halogens.

3. Warning – your safety during installation Remember that even 100°C can cause burns. Always avoid touching the bulb while it is on and immediately after switching it off. Before fitting or removing it, wait a few moments to be sure it has cooled down completely.

⭐MAGALL LED Bulbs – Safety and Compliance with EU Standards⭐

MAGALL LED bulbs comply with the EMC Directive 2014/30/EU and have passed EN IEC 55015:2019+A11:2020 testing.

MAGALL bulbs are designed not to interfere with other electrical devices and are resistant to external electromagnetic interference. This means stable, trouble-free operation throughout their service life, adding to the convenience, safety and comfort of everyday use of MAGALL LED lighting.

MAGALL LED bulbs carry the CE mark and meet European Union requirements for safety, health and environmental protection. The CE mark shows that the products have been tested for safe use and meet the strict quality and technical standards required in the EU.

☝️Are LED bulbs type-approved (homologated)?

All LED light sources available on the market were designed for headlights that meet the standards for halogen or conventional bulbs. The European Union has not yet adopted the comprehensive regulations needed to legalise LED retrofit light sources. When some sellers present information in their listings suggesting that LED bulbs are type-approved, this is intended to mislead customers into buying. Some of them even put an E… mark on the product to reinforce this impression. We do not use such practices.

In the European Union, automotive products must have UNECE certification to be used on public roads. Existing ECE certificates cover only halogen and xenon bulbs and LED light sources fitted as original equipment in new vehicles. However, there are no specific type-approval requirements or restrictions on using LED light sources on private roads, race tracks, etc. That is why leading manufacturers of automotive LED lighting mark their products "off-road use only" or "not for use on public roads".

Although the law has not changed, we believe our customers now know enough about LED light sources to make an informed choice and a satisfying purchase.

CANBUS – how it works and why it matters for LED bulbs

CAN BUS (Controller Area Network Bus) is a car's internal communication network that lets electronic modules (e.g. the BCM – Body Control Module) exchange data without extra wiring.

The computer does not check whether the bulb actually lights up – it measures the current draw and the circuit resistance.

• Test when the ignition is switched on: the computer sends a short pulse and checks whether the resistance falls within the so-called acceptance window, i.e. the permitted range of values.
• Continuous measurement while driving: in more advanced cars the BCM constantly monitors the current. If the LED bulb has different characteristics from a halogen (e.g. lower current draw), the system may treat this as a fault and display a "bulb out" message.

In practice, different cars have different tolerance ranges and CANBUS standards – they differ in data transfer speed, how the circuit is tested, and resistance and power draw requirements.

So saying that an LED bulb "has CANBUS" or "doesn't have CANBUS" is a simplification. It all depends on the tolerance of the vehicle's diagnostic system and the parameters of the LED bulb itself.

An illustrative example of how it works:

an H7 halogen bulb has a resistance of 3.6Ω

1.

• an example H7 LED bulb has a resistance of 10 Ω
• car A (acceptable range) 2.5–7 Ω – warning
• car B (acceptable range) 2–12 Ω – no warning
• car C (acceptable range) 3–5 Ω – warning

2.

• an example H7 LED bulb has a resistance of 6 Ω
• car A (acceptable range) 2.5–7 Ω – no warning
• car B (acceptable range) 2–12 Ω – no warning
• car C (acceptable range) 3–5 Ω – warning

3.

• an example H7 LED bulb has a resistance of 2.5 Ω
• car A (acceptable range) 2.5–7 Ω – no warning
• car B (acceptable range) 2–12 Ω – no warning
• car C (acceptable range) 3–5 Ω – warning (short circuit)
